SC08 SafeCheck 8 Bench Mounted Comprehensive Tester (Hipot)


CLARE SafeCheck 8, a bench-mounted instrument, ideal for electrical safety testing in the hire, rental & service industries. A simple user interface guides the operator through Class I, Class II & IEC extension power cord tests, with automated test sequences. The tester can also be used with a barcode reader which scans in the equipment’s ID number.

Part Number:
SC08

read more



Need Help ? Contact Us Request Demo Browse Accessories
Acutest's Price Promise
  • Competitive quote
  • Expert technical advice/demos
  • Trusted aftercare support



Manufacturer's RRP

£2258.00
2709.60 incl. VAT)
Add To Cart
  • Competitive quote
  • Expert technical advice/demos
  • Trusted aftercare support







CLARE SafeCheck 8 Bench Mounted Tester

The CLARE SafeCheck 8 offers a slick and easy way for electrical safety tests to be carried out on Class I and Class II tools/equipment, as well as IEC extension power cords within the hire and rental sectors.

This bench-mounted tester incorporates automatic test sequences and can be used with a barcode scanner for further productivity improvements; this helps eliminate potential data entry errors and to speed up the test process.

Pass and fail labels can be printed with ease if used in conjunction with the Desk Test n Tag printer

The results are recorded, and information is displayed on a large clear LCD screen, whilst the internal memory ensures up to 5000 results are stored for traceability.

SafeCheck 8 helps you meet your safety obligations whilst improving productivity.



CLARE SafeCheck 8 Key Features:

  • Class I, Class II and IEC power cord tests
  • Automatic safety testing streamlines the procedure
    • Predefined and custom test sequences
  • Bench mounted and easy to use
  • Earth / Ground Bond Test
  • AC Dielectric Strength (flash / hipot)
  • DC Insulation Resistance
  • IEC Cord Test
  • Power / Run Test
  • Earth Leakage
  • Touch Leakage
  • Storage of test results
  • Link to a printer or scanner for fast and traceable testing
  • Software/Label Printer/Barcode Scanner Compatible



CLARE SafeCheck 8 Ideal for:

  • Hire and rental sector
  • Service engineers





▶ Video: Alternatives to flash testing in the hire industry

Video for Seaward Clare recorded webinar



Technical Specification for: Clare SC08 SafeCheck 8 Bench Mounted Comprehensive Tester (Hipot)

Flash/Hipot Test (Class I)
Test Voltage Class l1.25kV AC
Display Range0.1 - 10mA AC
Resolution0.01mA
Accuracy+/- 5% +/- 2 digits
Pass Levels500V, 1250V AC
Flash/Hipot Test (Class I)
Test Voltage Class ll 2.5kV AC
Display Range0.1 - 10 mA AC
Resolution0.01mA
Accuracy+/- 5% +/- 2 digits
Pass LevelsSelectable up to 10mA
DC Insulation Test
Test Voltage 250/500V
Display Range 0.1 - 99.99MΩ
Accuracy+/- 5% +/- 2 digits (up to 19.99MΩ)
Earth/Ground Bond Test
Test Voltage6VAC (open circuit)
Test Current25A, 10A, 4A, 100mA AC into short circuit
Range0.04Ω - 20Ω
Resolution1mΩ
Accuracy+/- 5% +/- 2 digits
Pass LevelsSelectable up to 15mA
Substitute Leakage (Short to Case Test)
Test Voltage40VAC o/c
Display Range0.1 - 20.0mA AC
Resolution0.01mA
Accuracy +/- 10% +/- 2 digits (1.00 - 20mA)
Pass LevelsSelectable up to 15mA
Earth Leakage
Display Range0.1 - 20.0mA AC
Resolution0.01mA
Accuracy+/- 10% +/- 2 digits (1.00 - 20mA)
Pass LevelsSelectable up to 10mA
Power/Run/Load Tests
Resolution0.01kVA
Measured Load0 - 4kVA
Accuracy+/- 10 of reading, +/- 2 digits
IEC Power Cord Test
Test Voltage40VAC
DetectsGood, Open, Short, Reversed



Accessory Code Description Price (Ex VAT)
03918/2/SC08 HT Probe £75.00 ADD
194A919 RS232 Computer Lead £20.00 ADD
312A951 White Printer Labels £51.00 ADD
312A954 Orange Printer Labels £51.00 ADD
312A956 Yellow Printer Labels £47.00 ADD
312A957 Blue Printer Labels £47.00 ADD
312A961 Red Printer Labels £51.00 ADD
312A962 Green Printer Labels £51.00 ADD
43B679 Flash Probe £75.00 ADD
