Fluke
i2500-18 iFlex Flexible Current Probe


FLUKE i2500-18 iFlex Flexible Current Probes measurement capability: 2500 A ac current measurement with select FLUKE meters & works with frequency, inrush, & min/max functions on select FLUKE meters.

Part Number:
FLUKE-i2500-18

read more



Need Help ? Contact Us Request Demo
Acutest's Price Promise
  • Competitive quote
  • Expert technical advice/demos
  • Trusted aftercare support



Manufacturer's RRP

£175.00
210.00 incl. VAT)
Add To Cart
  • Competitive quote
  • Expert technical advice/demos
  • Trusted aftercare support







FLUKE i2500-18 iFlex Flexible Current Probe

The FLUKE iFlex flexible current probes expand the measurement range of the select FLUKE meters to 2500 A AC while providing the ultimate measurement flexibility. The iFlex probes connect directly to the meter, displaying current measurements without error prone scaling factors. The 1.8 m (6 ft) cord allows separation between the measurement location and the clamp meter making it easier to view the display. The large loop size and thin cross section allow measurement of awkward sized conductors and improved wire access in crowded spaces.

Available in 25 cm (10 in) and 45 cm (18 in) sizes.



▶ Video: FLUKE 381 in action with the iFlex!

Video thumbnail for the FLUKE 381 True RMS AC/DC Clamp Meter with Remote Display and iFlex



▶ Video: Tight spaces? See how handy the iFlex is!

FLUKE iFlex working in tight spaces!



FLUKE i2500-18 Key Features:

  • Size: 45 cm (18 in)
  • Expands the measurement range to 2500 A ac while providing increased display flexibility, ability to measure awkward sized conductors and improved wire access
  • CAT IV 600 V, CAT III 1000 V
  • 7.5 mm coil diameter allows measurement in tight spaces
  • Ergonomic design allows easy operation with one hand
  • 1.8 m (6 ft) cable
  • 3-year warranty
  • Safety Conformance: IEC/EN 61010-1:2001, 1000V CAT III, 600V CAT IV



Technical Specification for: Fluke i2500-18 iFlex Flexible Current Probe

RangeResolutionAccuracy
AC Current12500 A0.1 A3% ± 5 digits2
Frequency1500 Hz0.1 Hz0.5% ± 5 digits
External magnetic field rejection (with cable >10 cm from the coupling)40 dB
Inrush1
Safety ratingCAT III 1000 V, CAT IV 600 V
Position Sensitivity Specifications
Distance from Optimumi2500-18Additional iFlex Error
A1.4 in (35.6 mm)±0.5%
B2.0 in (50.8 mm)±1.0%
C2.5 in (63.5 mm)±2.0%
Measurement uncertainty assumes centralised primary conductor at optimum position, no external electrical or magnetic field, and within operating temperature.1 When used with compatible FLUKE meter. Accuracy stated includes probe and meter accuracy.2 For position accuracy at non-optimum positions, see Position sensitivity specifications table “A”
