Megger
EGIL Basic Circuit Breaker Analyser c/w Accessories


The Megger EGIL Basic Circuit Breaker Analyser is a compact, easy-to-use timer & motion analyser for testing medium & high-voltage circuit breakers in substations.

Part Number:
BM-19090

read more



Need Help ? Contact Us Request Demo Browse Accessories
Acutest's Price Promise
  • Competitive quote
  • Expert technical advice/demos
  • Trusted aftercare support

Product Options



Manufacturer's RRP

£13925.00
16710.00 incl. VAT)
Add To Cart
  • Competitive quote
  • Expert technical advice/demos
  • Trusted aftercare support







Megger EGIL Circuit Breaker Analyser

The Megger EGIL Circuit Breaker Analyser is a compact, reliable, and user-friendly instrument designed for testing medium- and high-voltage circuit breakers with a single interrupter per phase. Built with the same trusted technology found in Megger’s larger analyser systems, the EGIL offers a streamlined solution at a cost-effective price.

It is the perfect choice for smaller utilities, industrial substations, and maintenance contractors who require accurate results without the complexity or cost of larger breaker test systems. The EGIL Basic Circuit Breaker Analyser provides professional-grade timing and motion measurement, helping engineers and technicians ensure breaker reliability and operational safety.



Megger EGIL Key Features:

  • Easy to operate – Simple setup with ready-made cable sets and intuitive controls.
  • Compact and portable – Lightweight design with a robust transport case for field use.
  • High reliability – Proven Megger engineering ensures accuracy and long-term durability.
  • Cost-effective – Professional features at a fraction of the price of larger systems.
  • Versatile testing – Suitable for circuit breakers with single interrupters across medium-voltage substations and industrial facilities.
  • Three time channels – with common ground for main and pre-insertion resistor contacts.
  • Two galvanically isolated auxiliary time channels for auxiliary contact measurement.
  • Automatic coil current measurement – displayed in real time.
  • Built-in breaker control unit – with selectable operation sequences (C, O, C-O, O-C, O-C-O).
  • Optional motion channel – for travel and speed measurement of moving contacts.
  • Optional USB interface – or PC connection and CABA Win software integration.
  • Integrated thermal printer – for immediate graphical and numerical results on site.
  • Robust safety features – including galvanically isolated sockets and protective ground terminals.



Megger EGIL Control Panel:

Diagram of the Megger EGIL control panel

  1. Mains voltage changeover switch, 115/230 V AC
  2. SDRM (optional)
  3. Built-in coil current measurement
  4. Coil signal sequencer
  5. Three timing channels
  6. Two isolated timing channels for dry or wet contacts
  7. Optional analog input for travel or voltage measurement
  8. Optional USB interface for PC (supports CABA software)
  9. Built-in printer
  10. Isolated sockets
  11. Breaker state indicator
  12. Sequence buttons
  13. Breaker setting switch
  14. Menu-driven procedures
  15. MEASURE knob
  16. AUX 1 & 2 buttons for auxiliary contact timing



Applications:

The Megger EGIL is built for routine maintenance and commissioning of circuit breakers. Its applications include:

  • Timing measurements for main and auxiliary contacts.
  • Motion (travel) analysis when equipped with the optional analogue input channel.
  • Measurement of coil currents during breaker operation.
  • Static and dynamic resistance testing with the optional SDRM201 accessory.

Engineers use the EGIL Basic Circuit Breaker Analyser to detect issues such as slow operation, synchronisation errors between phases, and resistance problems in contacts. These insights help prevent costly outages, equipment damage, and safety hazards.



Why Choose the Megger EGIL?

The Megger EGIL Circuit Breaker Analyser is unique because it balances simplicity with performance. Unlike bulkier analysers, it doesn’t require extensive training. Simply connect the included cable sets, ground the device, and turn the MEASURE knob to get instant results.

For companies needing dependable test results without unnecessary complexity, the EGIL Basic Circuit Breaker Analyser provides the ideal balance of affordability and capability. It’s particularly attractive to:

  • Smaller utilities that cannot justify larger, more expensive analysers.
  • Large power companies seeking a supplementary analyser for routine checks.
  • Independent testing contractors who need portability and reliability in the field.



Technical Specifications (Summary)

FeatureDetails
Application fieldMedium-voltage substations and industrial sites
Time measurement1–100 s, resolution 0.1–10 ms, 3 channels with common ground
Auxiliary contacts2 galvanically isolated channels (wet or dry)
Current measurement±25 A per channel, 25 mA resolution
Breaker operationSequences C, O, C-O, O-C, O-C-O
Motion (optional)1 channel, ±4 V input, 2 mV resolution
PrinterBuilt-in thermal printer, 114 mm wide paper, 203 dpi resolution
Power supply115/230 V AC, 100 VA max
Dimensions354 × 210 × 181 mm, 5.9 kg
Operating temperature0°C to +50°C
Storage temperature–40°C to +70°C



Typical Workflow

Using the EGIL Basic Circuit Breaker Analyser is straightforward:

  • Ground the instrument and circuit breaker.
  • Connect timing cables to the main and auxiliary contacts.
  • Connect coil control cables to the trip and close circuits.
  • Select the desired breaker operation sequence.
  • Press the MEASURE knob to initiate testing.
  • View results instantly on the display or print them via the built-in printer.

Optional USB and motion modules extend this process with PC connectivity and advanced motion recording.



Megger EGIL Options:

The Megger EGIL range includes several configurations:

  • BM-19090 – EGIL Basic Circuit Breaker Analyser with Accessories
  • BM-19092 – EGIL with USB interface and CABA Win software
  • BM-19093 – EGIL with analogue input channel and USB interface
  • BM-19095 – EGIL with SDRM option, USB interface, and CABA Win software

Each model comes with essential cables, accessories, and a transport case for field use.

EGIL with the SDRM (SDRM201 and SDRM202) option together with the SDRM accessory enables static and dynamic resistance measurements. EGIL can also be equipped with an optional USB interface for communication with a PC and CABA Win Circuit Breaker Analysis Software.

Optional Accessories:

  • SDRM201 kit – For static and dynamic resistance measurements.
  • CABA Win software – Advanced circuit breaker analysis and reporting on PC.
  • Transducers – Linear and rotary motion transducers for travel and velocity measurement.
  • Extension cables – Available in various lengths for flexible field setups.
  • Flight case – Heavy-duty protection for transport and storage.



❓ Frequently Asked Questions (FAQ)

Q1: What makes the Megger EGIL different from larger breaker analysers?

A. The Megger EGIL Circuit Breaker Analyser offers the essential timing, motion, and current measurement functions found in larger analysers, but in a smaller, simpler, and more affordable package.

Q2: Can the EGIL test breakers with multiple interrupters per phase?

A. No. The EGIL is designed for breakers with one interrupter per phase. For multi-break systems, larger Megger analysers such as the TM1700 series are recommended.

Q3: Does the EGIL support PC connectivity?

A. Yes, selected models include a USB interface and CABA Win software for advanced reporting and analysis.

Q4: Can I measure travel (motion) with the EGIL Basic Circuit Breaker Analyser?

A. The base model does not include motion measurement, but you can add this functionality with the analogue input channel and compatible transducers.

Q5: Is the EGIL suitable for field testing?

A. Absolutely. Its compact design, rugged casing, and built-in printer make it ideal for on-site testing in substations and industrial environments.



The Takeaway

The Megger EGIL Circuit Breaker Analyser is a trusted solution for utilities, contractors, and maintenance teams who need accurate breaker performance testing without unnecessary complexity or cost. Whether you choose the EGIL Basic Circuit Breaker Analyser or one of the advanced configurations, you’ll benefit from Megger’s proven reliability, simple operation, and professional-grade results.



Technical Specification for: Megger EGIL Basic Circuit Breaker Analyser c/w Accessories

Product Downloads



Accessory Code Description Price (Ex VAT)
BL-90070 VoltageDivider VD401.R101 £1,475.00 ADD
BL-90165 CABA Hardware USB-FIBER Adapter R01A £1,135.00 ADD
CG-90225 SDRM 201/202 separate Cable for EGIL Only for upgrade (length 0 2m) £935.00 ADD
GA-00040 Cable 3 1m XLR/Banana MA61 £129.00 ADD
GA-00041 Cable 1 1m/XLR/Female MA61 £65.00 ADD
GA-00042 Cable 2 7 5m/XLR MA61 £160.00 ADD
GA-00082 Cable set 4x2m 2x2m black 2x2m red £165.00 ADD
GA-00150 Cable Extend EGIL 10m XLR 5P/XLR 5P £325.00 ADD
GA-00160 Cable timing EGIL 5m XLR 5P/clamps £325.00 ADD
GA-00170 Cable AUX1&2 EGIL 2m XLR 5P/banana plugs £240.00 ADD
GA-00231 Cable set TM1600/4 5m banan/clamp 4xblack 4xred £455.00 ADD
GA-00241 Cable set TM1600/4 10m banan/clamp 4xblack 4xred £605.00 ADD
GA-00251 Cable set TM1600/4 15m banan/clamp 4xblack 4xred £820.00 ADD
GA-00840 Cable Reel 20 m black TM1800 CG0228AE £470.00 ADD
GA-00842 Cable Reel 20 m red TM1800 CG0230AE £470.00 ADD
GA-00844 Cable Reel 20 m yellow TM1800 CG0231AE £470.00 ADD
GA-00845 Cable Reel 20 m green TM1800 £470.00 ADD
GA-00846 Cable Reel 20 m blue TM1800 £470.00 ADD
GA-01000 Open Analog Cable TM1800 CG0184BE £66.00 ADD
GA-01005 Analog Cable Egil/TM1600/TM1800 10m price on request
GD-00190 Transport case EGIL £990.00 ADD
XB-30020 Transducer TLH-500 with cable GA-00049 price on request
XB-30030 Transducer TS-150 with cable GA-00044 price on request
XB-30033 Transducer TS-25 with cable GA-00044 price on request
XB-30117 Transducer LWG-225 with cable GA-00050 price on request
XB-31010 Rotary Transducer Analog £725.00 ADD
XB-39030 Transducer Flex coupling d:6mm £135.00 ADD
XB-51010 Rotary Transd. Mount Kit £1,445.00 ADD
XB-51020 Universal Transd.MountKit price on request
XB-71010 Ready-to-use 1-ph Analog £2,020.00 ADD
