Kewtech KEWEVA EV Charger Tester
Simplify EV charge point testing with direct connection and one rotary dial.
Make EV charge point testing more straightforward with the Kewtech KEWEVA. This compact Type 2 testing adapter simulates the presence of an electric vehicle, allowing you to check charging equipment using a compatible multifunction tester. Suitable for single-phase and three-phase charge points, it plugs directly into the charging unit without a separate adapter cable to manage.
A single rotary dial selects standby, ready and charging states, while the automatic Control Pilot check confirms the charging station’s 1 kHz signal using a blue LED. Standard 4 mm test connections and clear voltage indicators help keep your testing set-up simple and organised.
Request a quote for the Kewtech KEWEVA today. Tell us which multifunction tester you use and the quantity you need, and ask for pricing and availability.
Kewtech KEWEVA Key Features:
- Direct Type 2 connection: An integrated IEC 62196-2 Type 2 male connector plugs into the charging unit without a separate adapter cable
- Single-phase and three-phase compatibility: Supports testing of both types of EV charging equipment with a suitable multifunction tester
- Simple rotary control: Select standby, ready and charging simulations using one dial
- Automatic Control Pilot check: Checks that the charging station’s PWM signal is at 1 kHz, with confirmation provided by a blue LED
- Standard test connections: Uses 4 mm connectors for connection to multifunction testers with EV charging point testing capabilities
- Clear voltage indication: Red LEDs show live status for each phase, with a separate red LED indicating voltage at the output connectors
- Low-resistance connections: Direct connections are designed to support accurate loop measurements
- Protective storage: Supplied with a durable carry case for transport between jobs
Test Connections and Terminal Identification
The KEWEVA provides colour-coded 4 mm terminals for connecting test leads from a compatible multifunction tester (MFT) with EV testing capabilities. These connections support electrical testing of single-phase and three-phase EV charging points.
- N (blue): Neutral terminal
- Earth (yellow/green): Protective earth (PE) terminal
- L1 (brown): Line / phase 1 terminal
- L2 (black): Line / phase 2 terminal
- L3 (grey): Line / phase 3 terminal
The printed yellow symbols highlight electrical hazard and general safety warnings. A separate red LED indicates when voltage is applied to the output connectors.
Why Choose the Kewtech KEWEVA?
The KEWEVA brings vehicle simulation, automatic Control Pilot checking and accessible test connections together in a compact adapter. Its direct connection reduces the cable handling involved in setting up, while the single rotary dial keeps state selection straightforward. For electricians testing EV charging installations, it provides a practical way to connect compatible multifunction test equipment to a Type 2 charging point.
▶ Reasons to buy the Kewtech KEWEVA EV:
▶ Discover the Kewtech KEWEVA EV Testing Adapter:
What Comes with the Kewtech KEWEVA?
- Kewtech KEWEVA EV Charge Point Test Adapter
- Durable Carry Case
Specifications:
| Features | |
| Connections and Test Functions |
| EV charging equipment compatibility | Single-phase and three-phase |
| EV charger connector | IEC 62196-2 Type 2 male |
| Test instrument connections | Standard 4 mm connectors |
| Multifunction tester requirements | EV charging point testing capabilities and standard 4 mm test connections |
| Control Pilot state simulation | A, B and C |
| Rotary dial selections | Standby, ready and charging |
| Automatic Control Pilot signal check | ✓ Checks for a 1 kHz PWM signal, confirmed by a blue LED |
| Phase live indication | ✓ Red LEDs for individual phases |
| Output voltage indication | ✓ Separate red LED |
| Electrical Ratings |
| Maximum single-phase input voltage | 250 V |
| Maximum three-phase input voltage | 430 V |
| Supply frequency | 50/60 Hz |
| Maximum current carrying capacity | 10 A, for intermittent testing purposes only |
| Safety standard and measurement category | BS EN 61010, CAT II 300 V |
| Environmental and Physical Specifications |
| Working temperature | 0 to 40 °C |
| Storage temperature | −10 to 50 °C |
| Humidity | 0 to 80% RH |
| Boxed dimensions, W × D × H | 90 × 90 × 231 mm |
| Listed weight | 0.52 kg |
| Carry case included | ✓ |
❓ Frequently Asked Questions (FAQ)
Q1: Which multifunction testers can I use with the Kewtech KEWEVA?
A. The KEWEVA works with multifunction testers that have EV charging point testing capabilities and standard 4 mm connections. Compatible Kewtech examples include the KT66DL and KT64DL. The adapter provides vehicle simulation and test connections, while your multifunction tester performs the electrical measurements.
Q2: Can the KEWEVA test single-phase and three-phase charging equipment?
A. Yes. It supports both single-phase and three-phase charging equipment with a Type 2 connection. The maximum input ratings are 250 V single-phase and 430 V three-phase, at 50/60 Hz.
Q3: How does the automatic Control Pilot check work?
A. The KEWEVA checks that the charging station’s Control Pilot PWM signal is at 1 kHz. A blue LED confirms this check, so an oscilloscope is not required for that function.
Q4: Does the KEWEVA need a separate adapter cable?
A. No separate cable is needed between the KEWEVA and the charging unit because its Type 2 male connector plugs directly into the unit. Your multifunction tester connects to the adapter through standard 4 mm test leads.
Equip your team for straightforward EV charge point testing. Request your Kewtech KEWEVA quotation and tell us your multifunction tester model, required quantity and delivery requirements.
