Socket & See Engineer DMM Digital Multimeter
6000 Count True RMS Digital Multimeter for Professional Electrical Testing
The Socket & See Engineer DMM Digital Multimeter is a versatile 6000 count True RMS multimeter designed for electrical testing, measurement and fault finding.
Combining AC/DC voltage and current measurement with resistance, continuity, capacitance, frequency, duty cycle and temperature functions, the Socket & See Engineer DMM brings a wide range of useful measurements together in one instrument. A backlit LCD helps make readings clear in poorly lit working areas, while the freeze/hold function allows a displayed measurement to be retained when required.
The meter also features non-contact AC voltage detection with audible and visual indication, alongside non-contact frequency detection. Auto power-off after approximately five minutes helps conserve battery life during everyday use.
With CAT III 1000V / CAT IV 600V measurement categories, dual-insulated test leads and GS38 compliant probes, the Socket and See Engineer DMM Digital Multimeter is designed for demanding electrical testing applications.
Request a competitive quote for the Socket & See Engineer DMM today – a versatile True RMS multimeter combining comprehensive measurement capabilities with practical diagnostic functions for professional electrical testing.
Socket & See Engineer DMM Key Features:
- 6000 count True RMS measurement for accurate electrical testing
- AC/DC voltage measurement up to 1000V
- AC/DC current measurement up to 10A
- Non-contact AC voltage detection with visual and audible indication
- Resistance measurement up to 60MΩ
- Capacitance measurement up to 100mF
- Temperature measurement from -40°C to 1000°C
- Continuity function with audible indication below approximately 50Ω
- Frequency and duty cycle measurement for additional diagnostic capability
- Freeze/Hold and Relative Reading functions for convenient measurement comparison
- Backlit LCD display for improved visibility
- Auto power-off helps preserve battery life
- External clamp adaptor input supports measurement up to 600A at 1mV = 1A
Why Choose the Socket & See Engineer DMM?
The Socket & See Engineer DMM is designed for users who need more than basic voltage and resistance measurement from their multimeter.
True RMS capability, a 6000-count display and a broad selection of electrical measurement functions make it suitable for testing, diagnostics and troubleshooting. The meter can measure AC/DC voltage up to 1000V, AC/DC current up to 10A and resistance up to 60MΩ, together with capacitance, frequency, duty cycle and temperature.
Non-contact AC voltage detection provides both visual and audible indication when voltage is detected above the stated threshold, while the continuity buzzer allows quick continuity checks.
For anyone looking for an Engineer‘s Digital Multimeter with comprehensive measurement capability, the Socket and See Engineer DMM provides a practical combination of electrical functions, safety features and everyday usability.
Specifications:
| Features | |
| Display Count | 6000 Count |
| AC/DC Voltage | Up to 1000V |
| AC/DC Current | Up to 10A |
| External Clamp Adaptor | Up to 600A, 1mV = 1A |
| Resistance | Up to 60MΩ |
| Continuity | Audible indication below approx. 50Ω |
| Capacitance | 10nF – 100mF |
| Diode Check | 3.0V |
| Frequency | 9.999Hz – 55.00kHz |
| Duty Cycle | 0.1 – 99.9% |
| Temperature Measurement | -40°C to 1000°C |
| Non-Contact Voltage Detection | Audible and visual, >100V AC |
| Hold Function | ✓ |
| Relative Reading | ✓ |
| Auto Power-Off | Approx. 5 minutes |
| Input Impedance | 10MΩ |
| Power Supply | 1 × 9V battery |
| Overvoltage Category | CAT III 1000V / CAT IV 600V |
| Safety Compliance | BS EN 61010-2-030:2010 |
| EMC Compliance | BS EN 61326-2-2:2013 |
| Test Leads | Dual insulated |
| Probes | GS38 compliant |
| Dimensions | 188 × 96 × 56mm |
| Weight | 415g without battery |
What comes with the Engineer DMM?
- Engineer DMM Digital Multimeter
- Test leads
- 9V battery
- K-Type temperature probe (-40°C to 250°C)
- Operating manual
❓ Frequently Asked Questions (FAQ)
Q1: Is the Socket & See Engineer DMM a True RMS multimeter?
A. Yes. The Socket & See Engineer DMM Digital Multimeter is a 6000 count True RMS instrument designed for a wide range of electrical measurements.
Q2: What can the Engineer DMM measure?
A. The meter provides AC/DC voltage and current measurement together with resistance, continuity, capacitance, diode testing, frequency, duty cycle and temperature measurement.
Q3: Does the Socket & See Engineer DMM have non-contact voltage detection?
A. Yes. The Socket and See Engineer DMM features non-contact AC voltage detection with both audible and visual indication.
Q4: What measurement category is the Engineer DMM?
A. The meter is rated CAT III 1000V / CAT IV 600V and is supplied with GS38 compliant probes.
Q5: Does the Engineer DMM have automatic power-off?
A. Yes. The meter automatically powers off after approximately five minutes, helping to conserve the 9V battery when the instrument is not being used.
